SGS Plastic Gel Seal Outdoor Fiber Optic Splice Box

SGS Plastic Gel Seal Outdoor Fiber Optic Splice Box

  • SGS Plastic Gel Seal Outdoor Fiber Optic Splice Box
SGS Plastic Gel Seal Outdoor Fiber Optic Splice Box
Product Details:
Place of Origin: China(Mainland)
Brand Name: HUIJIA
Certification: ISO,SGS,ROHS
Model Number: HJ1212S
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: PP Bag,Brown Carton
Delivery Time: 10 Work Days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 1000/PCS
Contact Now
Detailed Product Description
Application: BTS Installation Material: Plastic
Waterproof Level: IP68 Certification: ISO,SGS,ROHS
Lifespan: More Than 10 Years Rainstorm Resistance: 100E150mm/h
Inlet: 1/2" Jumper Cable(13-17mm) Oulet: Antenna Bolt
High Light:

HB SGS outdoor fiber optic splice box

,

SGS outdoor fiber optic splice box

,

SGS Plastic ofc joint closure

Gel Seal Closure For Electronic RF 1/2 Inch Jumper To 1/2" Feeder Cable Short Type HJ1212S





Installation:



          1. Open closure,place the connector inside.

          2. Close the closure

          3. Slash the pin

          4. The hole of pin should cover the eminent point of the closure

          5. Press the button,and push the pin

          6. Open the closure





Technical Parameter for Closure Model Number HJ1212S
Material Plastic, silica gel
Waterproof Rating IP68
Fireproof Rating HB
Lifespan More than 10 years
Temperature Range -40~65 Celsius degree
Rainstorm resistance 100E150mm/h
Ice-snow resistance Up to 100mm
Inlet 1/2” Jumper(13-17mm)
Outlet Antenna Bolt



Description:

HJ1212S gel seal closure is a new kind of weatherproofing kit.It is designed to quickly seal the antenna connector and feeder connectors in cellular sites.This closure contains an innovative gel material and provides an efficient block against moisture & salt mist.

HJ1212S gel seal closures have pass strict tests from lab and achieve good feedback from long-term practical application.The ease of installation and reusable feature makes them a cost-effective solution.

Advantages



· quick install, just take seconds.

· easy removable & reusable.

· one step install, simple, don't need training.

· assure a unifom and good sealing jobs.

· wraparound and no disconnection of the connectors.



Certificate

· The third party test report from CTTL (china telecommunication technology labs )

· Material safety ROHS report.



Engineering experience

· China Unicom

· China Mobile

· China Telecom
